Over-the-range microwave install: wall plate, top bolts and venting

An OTR microwave hangs on a wall plate anchored into at least one stud and is bolted up through the cabinet above. It ships set for one vent mode (often recirculating) and must be converted for outside venting through the wall or roof. Use the paper templates from the box; hole positions differ between brands.

Cross-checked ~120 min moderateBrands: All

Before you start

Two people to lift and hang the unit.
Microwaves contain a high-voltage capacitor: do not open the cabinet; installation work is on the outside only.
Use only metal duct for outside venting.
