Testing a powered three-wire sensor: supply, ground and signal (Hall, flow meter, pressure, turbidity)

Three-wire sensors have electronics inside and cannot be judged with an ohmmeter. The board supplies a DC voltage and ground, and reads a signal back. Test in that order at the sensor connector: supply, ground, signal. Missing supply points to the board or harness, not the sensor.

Cross-checked ~30 min moderateBrands: All
